Single Function Time Delay Relay, Octal, Off Delay, 1 Functions 24V AC/DC, DPDT MPN:TR-51628-14
Discount: See in Cart
Free Shipping
In Stock
Free Shipping
In Stock
SKU
510-G5234537
Single Function Time Delay Relay, Octal, Off Delay, 1 Functions 24V AC/DC, DPDT
The Macromatic Single Function Time Delay Relay is a versatile and reliable device that provides precise timing control for a wide range of applications. This octal-shaped relay can be used to delay the switching of a circuit for up to 15 minutes, making it ideal for automation, control systems, and industrial processes. With its adjustable potentiometer and DPDT contacts, it can handle currents up to 10A and voltages up to 240V AC. Perfect for applications such as lighting control, security systems, and HVAC systems, this relay offers a simple and effective solution for timing control needs.
Top product features:
- Adjustable Time Delay Function: The relay has an adjustable time delay function that can be set using a potentiometer, allowing users to customize the delay time to suit their needs.
- Dual-Pole Double-Throw (DPDT) Contacts: The relay features DPDT contacts, enabling users to control two separate circuits or switch two separate loads with a single relay.
- Off Delay Functionality: The relay has an off delay function, which allows users to set a delay time before a circuit or load is switched off, providing a safe and controlled shutdown.
Top product applications:
- Control Panel Lighting
- Industrial Automation Systems
- Home Security Systems
Single Function Time Delay Relay, Adjustment Method Potentiometer, Base Shape Octal, Coil Voltage 24V AC/DC, Contact Form DPDT, Contact Rating (AC) 10 A @ 240V, Contact Rating (DC) 10 A @ 30V, Current Rating 10 A, Number of Delay Functions 1, Delay Function Off Delay, Electrical Connection Socket, Flat Pin Width Not Applicable, IP Rating IP20, Input Voltage 24V AC/DC, Minimum Time Setting 9 sec, Maximum Time Setting 15 min, Number of Pins 11, Sealing Enclosed, Mounting Style Plug-In
Additional Information
- Country of Origin: US
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 2.60
- Package Width: 2.00
- Package Height: 4.30
- Package Weight: 0.25
Product info last updated on February 4, 2026 6:03am UTC
Category: Industrial Electrical Controls and Automation
