Single Function Time Delay Relay, Octal, On Delay, 1 Functions 120V AC/DC, DPDT MPN:TR-50222-10
Discount: See in Cart
Free Shipping
In Stock
Free Shipping
In Stock
SKU
510-G5234275
Single Function Time Delay Relay, Octal, On Delay, 1 Functions 120V AC/DC, DPDT
The Macromatic Single Function Time Delay Relay is a versatile and reliable solution for a wide range of applications. This octal-shaped relay features a potentiometer adjustment method, allowing for precise timing control. With a 1.8-180 second delay range, it's ideal for applications requiring a specific time delay, such as lighting control, security systems, and industrial automation. The relay's DPDT configuration and 10A current rating make it suitable for high-amperage applications. Its compact design and plug-in mounting style make it easy to integrate into existing systems, providing a reliable and efficient solution for a variety of industries and applications.
Top product features:
- Adjustable time delay setting via potentiometer
- DPDT (Double Pole Double Throw) contact form
- On delay function with a minimum time setting of 1.8 seconds and a maximum time setting of 180 seconds
Top product applications:
- Time Delay for Industrial Control Circuits
- Automated Lighting Control Systems
- Pump Start-Up Sequencing
Single Function Time Delay Relay, Adjustment Method Potentiometer, Base Shape Octal, Coil Voltage 120V AC/DC, Contact Form DPDT, Contact Rating (AC) 10 A @ 240V, Contact Rating (DC) 10 A @ 30V, Current Rating 10 A, Number of Delay Functions 1, Delay Function On Delay, Electrical Connection Socket, Flat Pin Width Not Applicable, IP Rating IP20, Input Voltage 120V AC/DC, Minimum Time Setting 1.8 sec, Maximum Time Setting 180 sec, Number of Pins 8, Sealing Enclosed, Mounting Style Plug-In
Additional Information
- Country of Origin: US
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 4.25
- Package Width: 2.50
- Package Height: 1.88
- Package Weight: 0.23
Product info last updated on February 3, 2026 7:28pm UTC
Category: Industrial Electrical Controls and Automation
