WashdownMotor, 1-1/2hp, 1750RPM, 230/460VAC MPN:056T17W99028
WashdownMotor, 1-1/2hp, 1750RPM, 230/460VAC
This 1.5 HP washdown motor from Leeson is designed for harsh environments, featuring a totally enclosed fan-cooled design and a NEMA Design B rating for high-torque applications. Suitable for use in a variety of industries, including food processing, pharmaceutical, and chemical manufacturing, this motor can withstand the rigors of continuous operation in temperatures up to 40°C. With a service factor of 1.15, it provides reliable performance and long lifespan, making it an ideal choice for applications requiring high-speed, high-torque operation in demanding environments. Its compact size and easy mounting make it a versatile solution for a range of industrial applications.
Top product features:
- Three-Phase Design
- Totally Enclosed Fan Cooled Enclosure
- Continuous Duty Cycle
Top product applications:
- Industrial Laundry Equipment
- Pump Stations
- Food Processing Machinery
Washdown Motor, Three Phase, Motor Design Three-Phase, 1 1/2 hp HP, Nameplate RPM 1,750 RPM, No. of Speeds 1, Voltage 230/460V AC, Full Load Amps 4.8/2.4 A, 56C Frame, Usable @ 208V Not Usable at 208V, Usable @ 200V Not Usable at 200V, 60/50 Hz Hz, Motor Service Factor 1.15, Motor Thermal Protection None, Ins. Class F, Max. Ambient Temp. 40 Degrees C, Duty Cycle Continuous, NEMA Design B, Motor Shaft Rotation CW/CCW, Motor Enclosure Design Totally Enclosed Fan Cooled, Motor Mounting Type C-Face
Additional Information
- Country of Origin: US
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 15 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 18.31
- Package Width: 13.50
- Package Height: 13.44
- Package Weight: 49.00
Product info last updated on March 6, 2026 5:51am UTC
Category: Motors
