Three-Phase Severe Duty Motor, 1 HP, 56C Frame, 230/460V AC Voltage, 1760 rpm Nameplate RPM MPN:056T17W99021
Three-Phase Severe Duty Motor, 1 HP, 56C Frame, 230/460V AC Voltage, 1760 rpm Nameplate RPM
This Leeson Three-Phase Severe Duty Motor is designed for heavy-duty applications requiring high reliability and efficiency. With a 1 HP rating and 1760 rpm, it's ideal for use in industrial settings such as manufacturing, mining, and oil and gas operations. The motor's severe duty design and totally enclosed fan cooled enclosure ensure reliable operation in harsh environments. Its high efficiency and continuous duty rating make it a cost-effective solution for applications requiring long-term operation. Suitable for use in applications such as conveyor systems, pumps, and fans, this motor provides a reliable and efficient solution for heavy-duty industrial needs.
Top product features:
- Three-phase operation provides a balanced power distribution for efficient motor performance.
- Totally enclosed fan cooled motor enclosure design helps to protect the motor from dust and moisture.
- Ball motor bearings ensure smooth and quiet motor operation.
Top product applications:
- Pumps and water treatment systems
- Conveyor systems and material handling equipment
- Industrial fans and blowers
Severe Duty Motor, Three-Phase, Totally Enclosed Fan Cooled Motor Enclosure Design, 1 HP, Nameplate RPM 1760 rpm, Frame 56C, Voltage 230/460V AC, 60 Hz Hz, Three Phase, Full Load Amps 3.2/1.6 A, C-Face Motor Mounting Type, Motor Thermal Protection None, Ins. Class F, Motor Service Factor 1.15, Ball Motor Bearings, Motor Frame Material Steel, Max. Ambient Temp. 40 Degrees C, CW/CCW Motor Shaft Rotation, Nominal Efficiency 85.5 Percent, Continuous Duty, 1701-1800, CE, CSA, UL Recognized
Additional Information
- Country of Origin: US
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 15.00
- Package Width: 11.00
- Package Height: 12.00
- Package Weight: 34.70
Product info last updated on April 7, 2026 6:29pm UTC
Category: Motors
