Permanent Split Capacitor General Purpose Farm Duty Motor, 1/4 HP, 48Z Frame, 115/230V AC Voltage MPN:048A17T2002
Permanent Split Capacitor General Purpose Farm Duty Motor, 1/4 HP, 48Z Frame, 115/230V AC Voltage
The Leeson Permanent Split Capacitor General Purpose Farm Duty Motor is a reliable and efficient solution for a wide range of applications on the farm. With a 1/4 HP rating and 1,625 RPM, this motor is perfect for powering small equipment and tools, such as pumps, waterers, and grain dryers. Its permanent split capacitor design provides a smooth and quiet operation, while its totally enclosed air-over design protects against dust and moisture. The motor is also equipped with auto thermal protection and a service factor of 1, making it a durable and long-lasting choice for continuous use in harsh farm environments.
Top product features:
- Single Phase Motor Design
- Permanent Split Capacitor Design
- Totally Enclosed Air-Over Motor Enclosure
Top product applications:
- Pumps and irrigation systems
- Well and borehole pumps
- Sewage and effluent pumps
Farm Duty Motor, Single Phase, Motor Design Permanent Split Capacitor, 1/4 hp HP, Nameplate RPM 1,625 RPM, No. of Speeds 1, Voltage 115/230V AC, Full Load Amps 3.0/1.5 A, 48Z Frame, Usable @ 208V Not Usable at 208V, Usable @ 200V Not Usable at 200V, 60 Hz Hz, Motor Service Factor 1, Motor Thermal Protection Auto, Ins. Class B, Max. Ambient Temp. 40 Degrees C, Duty Cycle Continuous, Motor Shaft Rotation CW/CCW, Motor Enclosure Design Totally Enclosed Air-Over, Motor Mounting Type Cradle Base
Additional Information
- Country of Origin: MX
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 12.44
- Package Width: 9.13
- Package Height: 8.06
- Package Weight: 18.00
Product info last updated on February 28, 2026 10:48am UTC
Category: Motors
