Vector Motor, 1/2 HP, 1.5 ft.-lb., 230/460V MPN:056H17T2018
Vector Motor, 1/2 HP, 1.5 ft.-lb., 230/460V
This 1/2 HP three-phase Vector Motor from Leeson is designed for high-efficiency operation in a variety of applications, including industrial machinery, pumps, and conveyors. With a 1,000:1 speed range and 1,725 nameplate RPM, it provides precise control over mechanical systems. The motor's compact 56C frame and continuous duty cycle make it ideal for use in tight spaces and demanding environments. Its high torque output of 1.5 ft-lb and 5,400 RPM maximum speed also enable efficient power transmission and processing. Suitable for use in 230/460V AC systems, this motor is a reliable choice for industrial applications that require precision and power.
Top product features:
- Three-phase operation
- Speed range of 1,000:1
- Continuous duty cycle
Top product applications:
- Pumps
- Conveyors
- Fans
Vector Motor, Three Phase, Motor Design Three-Phase, 1/2 HP, Nameplate RPM 1,725, No. of Speeds 1, Voltage 230/460V AC, Full Load Amps 1.8/0.90 A, 56C Frame, Torque 1.5 ft-lb, Max. Speed 5,400 RPM, Speed Range 1,000:1, Usable @ 208V Not Usable at 208V, Usable @ 200V Not Usable at 200V, 60 Hz Hz, Max. Operating Frequency 120 Hz, Motor Service Factor 1, Motor Thermal Protection None, Ins. Class H, Max. Ambient Temp. 104 Degrees F, Duty Cycle Continuous, NEMA Design A, Motor Shaft Rotation CW/CCW
Additional Information
- Country of Origin: ZZ
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 12.44
- Package Width: 9.13
- Package Height: 8.06
- Package Weight: 22.00
Product info last updated on March 29, 2026 8:57am UTC
Category: Motors
