Capacitor-Start General Purpose Motor, 1/2 hp HP, 115/208-230V AC Voltage, 56 Frame MPN:5KC49GN0022X
Capacitor-Start General Purpose Motor, 1/2 hp HP, 115/208-230V AC Voltage, 56 Frame
The Leeson 1/2 hp capacitor-start general purpose motor is a reliable and efficient solution for a wide range of applications. Suitable for use in 115/208-230V AC environments, this motor operates at 1,725 RPM and is designed for continuous duty cycles. Its open drip-proof enclosure and cradle base mounting make it easy to integrate into existing systems. With a service factor of 1.25 and thermal protection, this motor provides long-lasting performance and minimal maintenance. Ideal for use in commercial and industrial settings, this motor is perfect for fans, pumps, and other equipment that require consistent and reliable operation.
Top product features:
- Single Phase Motor Design
- Motor Thermal Protection is Auto
- Duty Cycle is Continuous
Top product applications:
- Pumps
- Fans
- Conveyors
General Purpose Motor, Single Phase, Motor Design Capacitor-Start, 1/2 hp HP, Nameplate RPM 1,725 RPM, No. of Speeds 1, Voltage 115/208-230V AC, Full Load Amps 8.6/4.3-4.1 A, 56 Frame, Usable @ 208V Usable at 208V, Usable @ 200V Not Usable at 200V, Hz 60 Hz, Motor Service Factor 1.25, Max. Ambient Temp. 40 Degrees C, Motor Thermal Protection Auto, Duty Cycle Continuous, Ins. Class B, Motor Enclosure Design Open Drip Proof, Motor Shaft Rotation CW/CCW, Motor Mounting Type Cradle Base
Additional Information
- Country of Origin: ZZ
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 13.69
- Package Width: 7.13
- Package Height: 7.50
- Package Weight: 21.00
Product info last updated on February 18, 2026 10:01am UTC
Category: Motors
