Permanent Split Capacitor General Purpose Farm Duty Motor, 1/2 HP, 48Y Frame, 115/230V AC Voltage MPN:048A11T2023
Permanent Split Capacitor General Purpose Farm Duty Motor, 1/2 HP, 48Y Frame, 115/230V AC Voltage
This 1/2 HP Permanent Split Capacitor General Purpose Farm Duty Motor from Leeson is designed for a variety of applications on the farm, including irrigation systems, water pumps, and grain handling equipment. Its single-phase design and 115/230V AC voltage make it a versatile choice for a range of uses. With a nameplate RPM of 1,075 and a service factor of 1, this motor is built for continuous duty cycles in temperatures up to 40 degrees C. Its totally enclosed air-over design provides protection from the elements, making it a reliable choice for farm equipment and machinery.
Top product features:
- Permanent Split Capacitor design for efficient and reliable operation
- Totally Enclosed Air-Over enclosure for protection from dust and moisture
- Continuous duty cycle for uninterrupted operation in demanding applications
Top product applications:
- Farm Irrigation Pumps
- Well Pumps
- Farming Equipment
Farm Duty Motor, Single Phase, Motor Design Permanent Split Capacitor, 1/2 hp HP, Nameplate RPM 1,075 RPM, No. of Speeds 1, Voltage 115/230V AC, Full Load Amps 6.4/3.2 A, 48Y Frame, Usable @ 208V Not Usable at 208V, Usable @ 200V Not Usable at 200V, 60 Hz Hz, Motor Service Factor 1, Motor Thermal Protection Auto, Ins. Class B, Max. Ambient Temp. 40 Degrees C, Duty Cycle Continuous, Motor Shaft Rotation CW/CCW, Motor Enclosure Design Totally Enclosed Air-Over, Motor Mounting Type Cradle Base
Additional Information
- Country of Origin: MX
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 12.44
- Package Width: 9.13
- Package Height: 8.06
- Package Weight: 22.00
Product info last updated on February 7, 2026 5:21pm UTC
Category: Motors
