Capacitor-Start General Purpose Motor, 1/3 hp HP, 115/208-230V AC Voltage, 56 Frame MPN:5KC36LN1X
Capacitor-Start General Purpose Motor, 1/3 hp HP, 115/208-230V AC Voltage, 56 Frame
The Leeson Capacitor-Start General Purpose Motor is a reliable and efficient solution for various applications. Suitable for use in a single phase, 115/208-230V AC voltage environment, this motor offers 1/3 hp horsepower and a nameplate RPM of 1,725. Its compact 56 frame design makes it ideal for a range of applications, including industrial machinery, commercial equipment, and residential appliances. With a continuous duty cycle and auto thermal protection, this motor ensures reliable operation and extends motor lifespan. Its open drip-proof enclosure and cradle base mounting type provide added durability and ease of installation.
Top product features:
- Capacitor-start design for improved motor efficiency and reliability
- Single-phase motor operation for a wide range of applications
- Continuous duty cycle for uninterrupted performance in demanding environments
Top product applications:
- Pumps and water treatment systems
- Fans and blowers in HVAC systems
- Conveyors and material handling equipment
General Purpose Motor, Single Phase, Motor Design Capacitor-Start, 1/3 hp HP, Nameplate RPM 1,725 RPM, No. of Speeds 1, Voltage 115/208-230V AC, Full Load Amps 6.0/3.2-3.0 A, 56 Frame, Usable @ 208V Usable at 208V, Usable @ 200V Not Usable at 200V, Hz 60/50 Hz, Motor Service Factor 1.35, Max. Ambient Temp. 40 Degrees C, Motor Thermal Protection Auto, Duty Cycle Continuous, Ins. Class B, Motor Enclosure Design Open Drip Proof, Motor Shaft Rotation CW/CCW, Motor Mounting Type Cradle Base
Additional Information
- Country of Origin: ZZ
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 13.69
- Package Width: 7.13
- Package Height: 7.50
- Package Weight: 18.00
Product info last updated on January 16, 2026 11:55am UTC
Category: Motors
