Capacitor-Start General Purpose Motor, 1/2 hp HP, 115/230V AC Voltage, 56 Frame MPN:056C17D2079
Capacitor-Start General Purpose Motor, 1/2 hp HP, 115/230V AC Voltage, 56 Frame
This 1/2 hp general purpose motor from Leeson is a reliable and efficient solution for a wide range of applications. Suitable for use in single-phase systems, it features a capacitor-start design for optimal performance and a durable 56 frame construction. With a nameplate RPM of 1,725, this motor is ideal for applications requiring continuous operation at moderate speeds. Its open drip-proof enclosure and cradle base mounting ensure easy installation and maintenance. Perfect for use in industrial settings, this motor is also suitable for commercial applications such as HVAC, water treatment, and pumping systems.
Top product features:
- Capacitor-start design allows for efficient motor operation
- Single-phase motor design enables operation with a single power source
- Open drip-proof motor enclosure design provides protection from environmental debris
Top product applications:
- Pumps and blowers for industrial and commercial settings
- Fans and ventilation systems for residential and commercial buildings
- Conveyors and material handling equipment for manufacturing and warehousing operations
General Purpose Motor, Single Phase, Motor Design Capacitor-Start, 1/2 hp HP, Nameplate RPM 1,725 RPM, No. of Speeds 1, Voltage 115/230V AC, Full Load Amps 7.2/3.6 A, 56 Frame, Usable @ 208V Not Usable at 208V, Usable @ 200V Not Usable at 200V, Hz 60 Hz, Motor Service Factor 1.25, Max. Ambient Temp. 40 Degrees C, Motor Thermal Protection Auto, Duty Cycle Continuous, Ins. Class B, Motor Enclosure Design Open Drip Proof, Motor Shaft Rotation CW/CCW, Motor Mounting Type Cradle Base
Additional Information
- Country of Origin: MX
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 12.44
- Package Width: 9.13
- Package Height: 8.06
- Package Weight: 20.00
Product info last updated on February 20, 2026 12:08pm UTC
Category: Motors
