Capacitor-Start/Run General Purpose Motor, 1 hp, 1/3 hp HP, 208-230/190-220V AC Voltage, 56H Frame MPN:5KCR48TN3084X
Capacitor-Start/Run General Purpose Motor, 1 hp, 1/3 hp HP, 208-230/190-220V AC Voltage, 56H Frame
This 1 hp single phase motor from Leeson is a reliable and efficient choice for a variety of applications. Suitable for use in 208-230/190-220V AC environments, it features a capacitor-start/run design and two speeds, making it ideal for applications requiring a range of power levels. The motor's open drip-proof enclosure and continuous duty cycle make it well-suited for use in industrial settings. Its compact size and lightweight design also make it easy to integrate into new or existing systems. Whether used for pumping, conveying, or other industrial processes, this motor provides reliable and efficient performance.
Top product features:
- Capacitor-start/run design provides efficient starting and running capabilities
- Single phase motor design allows for use in a variety of applications
- Open drip proof enclosure design protects against dust and water ingress
Top product applications:
- Pumps
- Fans
- Conveyors
General Purpose Motor, Single Phase, Motor Design Capacitor-Start/Run, 1 hp, 1/3 hp HP, Nameplate RPM 1,725/1,140 RPM, No. of Speeds 2, Voltage 208-230/190-220V AC, Full Load Amps 5.4/3.7 A, 56H Frame, Usable @ 208V Usable at 208V, Usable @ 200V Not Usable at 200V, Hz 60/50 Hz, Motor Service Factor 1, Max. Ambient Temp. 50 Degrees C, Motor Thermal Protection Auto, Duty Cycle Continuous, Ins. Class B, Motor Enclosure Design Open Drip Proof, Motor Shaft Rotation CW/CCW
Additional Information
- Country of Origin: ZZ
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 15.14
- Package Width: 10.19
- Package Height: 9.50
- Package Weight: 36.00
Product info last updated on March 2, 2026 12:52am UTC
Category: Motors
