General Purpose Farm Duty Motor, Split-Phase, 1/4 HP, 115V AC, 1, 725 Nameplate RPM, 48Y Frame MPN:048S17T2004
General Purpose Farm Duty Motor, Split-Phase, 1/4 HP, 115V AC, 1, 725 Nameplate RPM, 48Y Frame
This 1/4 HP, 115V AC general purpose farm duty motor from Leeson is designed for a variety of applications including irrigation, water pumping, and agricultural equipment. Its split-phase design and continuous duty cycle make it suitable for heavy use in demanding farm environments. The motor's totally enclosed air-over design provides protection from dust and moisture, while its CW/CCW shaft rotation allows for flexibility in mounting and installation. With a high thermal protection rating and a robust construction, this motor is a reliable choice for farmers and agricultural professionals who require a rugged and dependable motor solution.
Top product features:
- Split-phase motor design for efficient operation
- Totally enclosed air-over motor enclosure for protection from dust and debris
- Continuous duty cycle for reliable performance in demanding applications
Top product applications:
- Pumps and irrigation systems for small-scale farms or rural homes
- Fans and ventilation systems for agricultural buildings or greenhouses
- Small machinery and equipment such as grain sifters or seed cleaners
Farm Duty Motor, Single Phase, Motor Design Split-Phase, 1/4 hp HP, Nameplate RPM 1,725 RPM, No. of Speeds 1, Voltage 115V AC, Full Load Amps 4 A, 48Y Frame, Usable @ 208V Not Usable at 208V, Usable @ 200V Not Usable at 200V, 60 Hz Hz, Motor Service Factor 1, Motor Thermal Protection Manual, Ins. Class B, Max. Ambient Temp. 40 Degrees C, Duty Cycle Continuous, Motor Shaft Rotation CW/CCW, Motor Enclosure Design Totally Enclosed Air-Over, Motor Mounting Type Stud
Additional Information
- Country of Origin: ZZ
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 11.06
- Package Width: 6.75
- Package Height: 6.62
- Package Weight: 10.00
Product info last updated on February 27, 2026 11:57am UTC
Category: Motors
