Condenser Fan Motor, 1-1/2 HP, 56H Frame MPN:5K49PN4088X
Discount: See in Cart
Free Shipping
In Stock
Free Shipping
In Stock
SKU
510-G7347300
Condenser Fan Motor, 1-1/2 HP, 56H Frame
This 1.5 HP condenser fan motor from Leeson is a reliable and efficient solution for various applications. Suitable for use in three-phase systems, it operates at 1,725 RPM and can handle continuous duty cycles. The motor's open drip-proof design and cradle base mounting type provide easy installation and maintenance. With a service factor of 1.15 and thermal protection, it ensures optimal performance and longevity. Ideal for industrial and commercial settings, this motor is perfect for HVAC systems, condensers, and blowers, providing a cost-effective and efficient cooling solution. Its compact design and high capacity make it a versatile choice for various applications.
Top product features:
- Three-phase operation
- Continuous duty cycle
- Open drip-proof motor enclosure design
Top product applications:
- HVAC Systems
- Central Air Handling Units
- Commercial Ventilation Systems
Fan and Blower Motor, Three Phase, Motor Design Three-Phase, 1 1/2 hp HP, Nameplate RPM 1,725 RPM, No. of Speeds 1, Voltage 200-230/460V AC, 5.1-5.2/2.6 A Full Load Amps, 56H Frame, 60 Hz Hz, Usable @ 208V Usable at 208V, Usable @ 200V Not Usable at 200V, Motor Service Factor 1.15, Motor Thermal Protection Auto, Ins. Class B, Duty Cycle Continuous, Max. Ambient Temp. 40 Degrees C, Motor Shaft Rotation CW/CCW, Motor Enclosure Design Open Drip Proof, Motor Mounting Type Cradle Base
Additional Information
- Country of Origin: MX
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 15.63
- Package Width: 9.88
- Package Height: 7.50
- Package Weight: 31.00
Product info last updated on February 27, 2026 11:04am UTC
Category: Motors
