Condenser Fan Motor, 1 hp MPN:056T11O5302
Discount: See in Cart
Free Shipping
In Stock
Free Shipping
In Stock
SKU
510-G7347127
Condenser Fan Motor, 1 hp
This 1 hp condenser fan motor from Leeson is a reliable and efficient solution for a variety of applications, including commercial and industrial HVAC systems. With a continuous duty cycle and 1,140 RPM, it provides consistent airflow and cooling performance. The motor's open air over design and belly band mounting type make it easy to install and maintain. Its compact size and lightweight design also make it ideal for use in tight spaces. This motor is usable at 208V and 200V, making it a versatile option for different system configurations.
Top product features:
- Three Phase Operation
- Operates at 1,140 RPM
- Continuous Duty Cycle
Top product applications:
- HVAC systems
- Air conditioning units
- Commercial refrigeration systems
Condenser Fan Motor, Three Phase, Motor Design Three-Phase, 1 hp HP, Nameplate RPM 1,140 RPM, No. of Speeds 1, Voltage 200-230/460V AC, 4.0-4.2/2.1 A Full Load Amps, 56Y Frame, Output Watts 750 W, 60/50 Hz Hz, Usable @ 208V Usable at 208V, Usable @ 200V Usable at 200V, Motor Service Factor 1, Motor Thermal Protection Auto, Ins. Class H, Duty Cycle Continuous, Max. Ambient Temp. 70 Degrees C, Motor Shaft Rotation CW/CCW, Motor Enclosure Design Open Air Over, Motor Mounting Type Belly Band
Additional Information
- Country of Origin: MX
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 16.56
- Package Width: 7.50
- Package Height: 7.50
- Package Weight: 29.00
Product info last updated on February 27, 2026 2:30pm UTC
Category: Motors
