Condenser Fan Motor, 1 HP, 56 Frame, 1 Speed, Open Dripproof, Cradel Base Mount, 208-230/460V AC MPN:5K46MN4087
Discount: See in Cart
Free Shipping
In Stock
Free Shipping
In Stock
SKU
510-G7342577
Condenser Fan Motor, 1 HP, 56 Frame, 1 Speed, Open Dripproof, Cradel Base Mount, 208-230/460V AC
This 1 HP, 56 frame condenser fan motor from Leeson is a reliable and efficient solution for various applications. Suitable for use in a wide range of industries, including commercial and industrial settings, this motor provides a continuous duty cycle and operates at a maximum ambient temperature of 40 degrees C. Its open drip-proof design and cradle base mount make it easy to install and maintain. With a nameplate RPM of 1,725 and a motor service factor of 1.15, this motor is ideal for applications requiring high performance and reliability.
Top product features:
- Three-phase operation
- Open drip-proof enclosure design
- Continuous duty cycle
Top product applications:
- HVAC Systems
- Industrial Fans
- Centrifugal Pumps
Fan and Blower Motor, Three Phase, Motor Design Three-Phase, 1 hp HP, Nameplate RPM 1,725 RPM, No. of Speeds 1, Voltage 208-230/460V AC, 3.6-3.8/1.9 A Full Load Amps, 56 Frame, 60 Hz Hz, Usable @ 208V Usable at 208V, Usable @ 200V Not Usable at 200V, Motor Service Factor 1.15, Motor Thermal Protection None, Ins. Class B, Duty Cycle Continuous, Max. Ambient Temp. 40 Degrees C, Motor Shaft Rotation CW/CCW, Motor Enclosure Design Open Drip Proof, Motor Mounting Type Cradle Base
Additional Information
- Country of Origin: MX
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 13.69
- Package Width: 7.13
- Package Height: 7.50
- Package Weight: 27.00
Product info last updated on February 26, 2026 10:08pm UTC
Category: Motors
