Condenser Fan Motor, 1 HP, 56Z Frame MPN:5KC49NN0061T
Discount: See in Cart
Free Shipping
In Stock
Free Shipping
In Stock
SKU
510-G7260053
Condenser Fan Motor, 1 HP, 56Z Frame
This 1 HP condenser fan motor from Leeson is a reliable and efficient solution for various applications. Suitable for use in single-phase systems, it features a capacitor-start motor design and a 56Z frame for optimal performance. With a maximum ambient temperature of 40 degrees C and a continuous duty cycle, it can handle demanding tasks. The motor's open drip-proof enclosure ensures protection from dust and moisture, making it ideal for use in commercial and industrial settings. Its compact size and lightweight design also make it easy to install and maintain, providing a cost-effective solution for HVAC and ventilation systems.
Top product features:
- Single Phase Motor Design
- Capacitor-Start Motor Design for Efficient Operation
- Continuous Duty Cycle Capability
Top product applications:
- Air Conditioning Unit
- Commercial HVAC System
- Industrial Fan System
Fan and Blower Motor, Single Phase, Motor Design Capacitor-Start, 1 hp HP, Nameplate RPM 1,725 RPM, No. of Speeds 1, Voltage 115/208-230V AC, 14.4/7.2-7.2 A Full Load Amps, 56Z Frame, 60 Hz Hz, Usable @ 208V Usable at 208V, Usable @ 200V Not Usable at 200V, Motor Service Factor 1.15, Motor Thermal Protection Auto, Ins. Class B, Duty Cycle Continuous, Max. Ambient Temp. 40 Degrees C, Motor Shaft Rotation CW/CCW, Motor Enclosure Design Open Drip Proof, Motor Mounting Type Cradle Base
Additional Information
- Country of Origin: MX
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 15.44
- Package Width: 10.19
- Package Height: 9.50
- Package Weight: 27.00
Product info last updated on February 3, 2026 3:52pm UTC
Category: Motors
