Condenser Fan Motor, 3/4 hp MPN:056T11O5301
Condenser Fan Motor, 3/4 hp
This 3/4 hp condenser fan motor from Leeson is a reliable and efficient solution for various applications. Designed for continuous use in three-phase systems, it operates at 1,140 RPM and provides 560 watts of output. Its open-air over motor design and belly band mounting type make it suitable for use in commercial and industrial settings. The motor's auto thermal protection and Class B insulation ensure safe and reliable operation in temperatures up to 70 degrees C. Ideal for use in air conditioning and refrigeration systems, this motor is a great choice for applications requiring a high level of performance and durability.
Top product features:
- Three Phase operation
- Continuous Duty Cycle
- Auto Thermal Protection
Top product applications:
- Air Conditioning Systems
- Heating Ventilation and Air Conditioning (HVAC) Systems
- Commercial Refrigeration Units
Condenser Fan Motor, Three Phase, Motor Design Three-Phase, 3/4 hp HP, Nameplate RPM 1,140 RPM, No. of Speeds 1, Voltage 200-230/460V AC, 3.2-3.2/1.6 A Full Load Amps, 56Y Frame, Output Watts 560 W, 60/50 Hz Hz, Usable @ 208V Usable at 208V, Usable @ 200V Usable at 200V, Motor Service Factor 1, Motor Thermal Protection Auto, Ins. Class B, Duty Cycle Continuous, Max. Ambient Temp. 70 Degrees C, Motor Shaft Rotation CW/CCW, Motor Enclosure Design Open Air Over, Motor Mounting Type Belly Band
Additional Information
- Country of Origin: MX
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 16.56
- Package Width: 7.50
- Package Height: 7.50
- Package Weight: 25.00
Product info last updated on January 22, 2026 11:44am UTC
Category: Motors
