Condenser Fan Motor, 1 HP, 56 Frame MPN:056T17D2101
Discount: See in Cart
Free Shipping
In Stock
Free Shipping
In Stock
SKU
510-G7246640
Condenser Fan Motor, 1 HP, 56 Frame
This Leeson Condenser Fan Motor is a reliable and efficient solution for various applications, including commercial and industrial settings. With a 1 HP rating and 56 frame design, it's suitable for use in condenser units, air handlers, and other HVAC equipment. The motor's three-phase design and 1,725 RPM nameplate speed make it ideal for applications that require high airflow and efficiency. Its continuous duty cycle and open drip-proof enclosure ensure reliable operation in demanding environments, while its compact size and lightweight design make it easy to install and maintain.
Top product features:
- Three-phase operation
- Operates at 1,725 RPM
- Open drip proof motor enclosure design
Top product applications:
- HVAC Systems
- Commercial Air Handling Units
- Industrial Ventilation Systems
Fan and Blower Motor, Three Phase, Motor Design Three-Phase, 1 hp HP, Nameplate RPM 1,725 RPM, No. of Speeds 1, Voltage 208-230/460V AC, 3.4-3.4/1.7 A Full Load Amps, 56 Frame, 60/50 Hz Hz, Usable @ 208V Usable at 208V, Usable @ 200V Not Usable at 200V, Motor Service Factor 1.15, Motor Thermal Protection Auto, Ins. Class B, Duty Cycle Continuous, Max. Ambient Temp. 40 Degrees C, Motor Shaft Rotation CW/CCW, Motor Enclosure Design Open Drip Proof, Motor Mounting Type Cradle Base
Additional Information
- Country of Origin: MX
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 13.25
- Package Width: 7.00
- Package Height: 6.94
- Package Weight: 24.00
Product info last updated on February 2, 2026 6:01pm UTC
Category: Motors
