Condenser Fan Motor, 1/6 HP, 48Y Frame MPN:048S17D2053
Discount: See in Cart
Free Shipping
In Stock
Free Shipping
In Stock
SKU
510-G7244078
Condenser Fan Motor, 1/6 HP, 48Y Frame
This condenser fan motor from Leeson is a reliable and efficient solution for various applications. With a 1/6 HP rating and 1,725 RPM, it provides consistent performance in fan and blower systems. Suitable for single-phase operations, this motor can handle continuous duty cycles and operates within a maximum ambient temperature of 40 degrees C. Its open drip-proof design and cradle base mounting make it easy to integrate into existing systems. Perfect for use in residential and commercial settings, this motor is ideal for applications such as HVAC systems, ventilation systems, and industrial fans, providing reliable airflow and optimal performance.
Top product features:
- Single phase operation allows for efficient use in a variety of applications
- Motor design is split-phase for reliable and consistent performance
- Continuous duty cycle enables uninterrupted operation for extended periods
Top product applications:
- HVAC systems
- Industrial equipment ventilation
- Air purification systems
Fan and Blower Motor, Single Phase, Motor Design Split-Phase, 1/6 hp HP, Nameplate RPM 1,725 RPM, No. of Speeds 1, Voltage 115V AC, 3.6 A Full Load Amps, 48Y Frame, 60 Hz Hz, Usable @ 208V Not Usable at 208V, Usable @ 200V Not Usable at 200V, Motor Service Factor 1.35, Motor Thermal Protection Auto, Ins. Class B, Duty Cycle Continuous, Max. Ambient Temp. 40 Degrees C, Motor Shaft Rotation CW/CCW, Motor Enclosure Design Open Drip Proof, Motor Mounting Type Cradle Base, Motor Frame Material Steel
Additional Information
- Country of Origin: MX
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 11.06
- Package Width: 6.75
- Package Height: 6.62
- Package Weight: 13.00
Product info last updated on February 6, 2026 1:05am UTC
Category: Motors
