Condenser Fan Motor, 1/4 hp MPN:048A11T569
Condenser Fan Motor, 1/4 hp
This 1/4 hp condenser fan motor from Leeson is a reliable and efficient solution for various applications, including HVAC systems, industrial cooling, and commercial refrigeration. Its permanent split capacitor design ensures smooth and quiet operation, while its totally enclosed air-over enclosure protects the motor from dust and moisture. With a nameplate RPM of 1,075 and a voltage range of 208-230V AC, this motor is suitable for use in a variety of environments and can handle continuous duty cycles. Its compact design and durable construction make it an ideal choice for applications where space and reliability are crucial.
Top product features:
- Permanent Split Capacitor motor design
- Totally Enclosed Air-Over motor enclosure
- Continuous duty cycle operation
Top product applications:
- Air Conditioning and Heating Systems
- Industrial Ventilation Systems
- Commercial Refrigeration Units
Condenser Fan Motor, Single Phase, Motor Design Permanent Split Capacitor, 1/4 hp HP, Nameplate RPM 1,075 RPM, No. of Speeds 1, Voltage 208-230V AC, 1.4 A Full Load Amps, 48Y Frame, Output Watts 190 W, 60 Hz Hz, Usable @ 208V Usable at 208V, Usable @ 200V Not Usable at 200V, Motor Service Factor 1, Motor Thermal Protection Auto, Ins. Class B, Duty Cycle Continuous, Max. Ambient Temp. 60 Degrees C, Motor Shaft Rotation CW/CCW, Motor Enclosure Design Totally Enclosed Air-Over
Additional Information
- Country of Origin: MX
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 13.25
- Package Width: 7.00
- Package Height: 6.94
- Package Weight: 12.00
Product info last updated on February 6, 2026 7:21pm UTC
Category: Motors
