Capacitor-Start General Purpose Motor, 3/4 hp HP, 115/230V AC Voltage, 56 Frame MPN:5KC46LN0254X
Capacitor-Start General Purpose Motor, 3/4 hp HP, 115/230V AC Voltage, 56 Frame
The Leeson Capacitor-Start General Purpose Motor is a reliable and efficient solution for a wide range of applications. With its 3/4 horsepower rating, it can handle demanding tasks, and its single-phase design makes it easy to install and integrate into existing systems. Suitable for use in 115/230V AC environments, this motor offers a high level of versatility and flexibility. Its open drip-proof enclosure ensures safe operation in harsh conditions, and its continuous duty cycle makes it ideal for applications requiring sustained performance. Perfect for use in manufacturing, commercial, and industrial settings, this motor delivers reliable power and long-lasting performance.
Top product features:
- Capacitor-start design for improved efficiency and reliability
- Single-phase motor operation for compatibility with standard household electrical systems
- Open drip-proof enclosure design for protection against dust and moisture
Top product applications:
- Home Air Conditioning and Heating Units
- Water Pumps
- Fans
General Purpose Motor, Single Phase, Motor Design Capacitor-Start, 3/4 hp HP, Nameplate RPM 1,725 RPM, No. of Speeds 1, Voltage 115/230V AC, Full Load Amps 13.2/6.6 A, 56 Frame, Usable @ 208V Not Usable at 208V, Usable @ 200V Not Usable at 200V, Hz 60 Hz, Motor Service Factor 1, Max. Ambient Temp. 40 Degrees C, Motor Thermal Protection Auto, Duty Cycle Continuous, Ins. Class B, Motor Enclosure Design Open Drip Proof, Motor Shaft Rotation CW/CCW, Motor Mounting Type Cradle Base
Additional Information
- Country of Origin: MX
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 13.69
- Package Width: 7.13
- Package Height: 7.50
- Package Weight: 25.00
Product info last updated on February 7, 2026 11:37am UTC
Category: Motors
