Capacitor-Start General Purpose Motor, 1/3 hp HP, 115/230V AC Voltage, 48 Frame MPN:048C17D2029
Capacitor-Start General Purpose Motor, 1/3 hp HP, 115/230V AC Voltage, 48 Frame
This 1/3 hp capacitor-start general purpose motor from Leeson is a reliable and efficient solution for a wide range of applications. Suitable for use in 115/230V AC environments, this motor offers a high level of performance and durability. Its single-phase design and open drip-proof enclosure make it easy to integrate into existing systems, while its continuous duty cycle and thermal protection ensure reliable operation. Ideal for use in industrial settings, such as manufacturing and processing facilities, this motor is also suitable for use in commercial settings, such as restaurants and retail spaces. Its compact design makes it easy to mount and maintain.
Top product features:
- Capacitor-start design for efficient starting and running
- Single-phase motor operation for simple installation and control
- Open drip-proof motor enclosure for protection against dust and debris
Top product applications:
- Industrial machinery
- Pumps and compressors
- Conveyors and material handling equipment
General Purpose Motor, Single Phase, Motor Design Capacitor-Start, 1/3 hp HP, Nameplate RPM 1,725 RPM, No. of Speeds 1, Voltage 115/230V AC, Full Load Amps 7.0/3.5 A, 48 Frame, Usable @ 208V Not Usable at 208V, Usable @ 200V Not Usable at 200V, Hz 60 Hz, Motor Service Factor 1, Max. Ambient Temp. 40 Degrees C, Motor Thermal Protection Auto, Duty Cycle Continuous, Ins. Class B, Motor Enclosure Design Open Drip Proof, Motor Shaft Rotation CW/CCW, Motor Mounting Type Cradle Base
Additional Information
- Country of Origin: MX
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 12.44
- Package Width: 9.13
- Package Height: 8.06
- Package Weight: 16.00
Product info last updated on February 3, 2026 7:48pm UTC
Category: Motors
