Capacitor-Start General Purpose Motor, 1 hp HP, 115/208-230V AC Voltage, 56 Frame MPN:5KC49PN0164X
Capacitor-Start General Purpose Motor, 1 hp HP, 115/208-230V AC Voltage, 56 Frame
This Leeson Capacitor-Start General Purpose Motor is a reliable and efficient solution for a wide range of applications, including industrial and commercial settings. With a powerful 1 hp output and 1,725 RPM, it's ideal for use in machinery, equipment, and other applications where high-speed operation is required. The motor's capacitor-start design ensures smooth and consistent performance, while its open drip-proof enclosure protects against dust and moisture. Suitable for continuous duty cycles, this motor is a great choice for applications in environments up to 40°C, including manufacturing, pumping, and conveyor systems.
Top product features:
- Capacitor-start design for improved motor efficiency
- Single-phase operation for simplified installation
- Continuous duty cycle for reliable operation in demanding applications
Top product applications:
- Pump applications for residential and commercial use
- Fans and blowers for general ventilation and air circulation
- Power tools and machinery for industrial and construction settings
General Purpose Motor, Single Phase, Motor Design Capacitor-Start, 1 hp HP, Nameplate RPM 1,725 RPM, No. of Speeds 1, Voltage 115/208-230V AC, Full Load Amps 14.7/7.4-7.2 A, 56 Frame, Usable @ 208V Usable at 208V, Usable @ 200V Not Usable at 200V, Hz 60 Hz, Motor Service Factor 1.15, Max. Ambient Temp. 40 Degrees C, Motor Thermal Protection Auto, Duty Cycle Continuous, Ins. Class B, Motor Enclosure Design Open Drip Proof, Motor Shaft Rotation CW/CCW, Motor Mounting Type Cradle Base
Additional Information
- Country of Origin: ZZ
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 13.69
- Package Width: 7.13
- Package Height: 7.50
- Package Weight: 29.00
Product info last updated on February 27, 2026 4:28am UTC
Category: Motors
