Air Compressor Motor, 1 HP, 10.6/5.5-5.3A MPN:056B34D2029
Air Compressor Motor, 1 HP, 10.6/5.5-5.3A
Power your air compressor with the reliable Leeson 1 HP motor, designed for continuous duty cycles in a variety of applications. Suitable for single-phase systems, this motor features a capacitor-start/run design, ensuring efficient operation and extended lifespan. Its compact 56 frame size allows for easy installation in tight spaces, making it ideal for use in garages, workshops, and small manufacturing facilities. With a maximum ambient temperature of 40°C and a robust steel frame, this motor can withstand demanding conditions, providing a reliable source of power for pneumatic tools and equipment.
Top product features:
- Single Phase design allows for efficient operation in a variety of applications
- Capacitor-Start/Run motor design provides improved starting torque and efficiency
- 56 Frame motor design offers a compact and rugged construction
Top product applications:
- Air Compressor Motor suitable for small to medium-sized air compressors used in garages, workshops, and small industrial settings.
- Air Compressor Motor used in commercial and industrial settings to power air tools, pneumatic machinery, and other equipment.
- Air Compressor Motor used in construction and manufacturing industries to power air-powered tools, such as drills, saws, and sanders.
Air Compressor Motor, Single Phase, Motor Design Capacitor-Start/Run, 1 hp HP, Nameplate RPM 3,450 RPM, No. of Speeds 1, Voltage 115/208-230V AC, Full Load Amps 10.6 A/5.5-5.3 A, 56 Frame, 60 Hz Hz, Motor Service Factor 1.15, Motor Thermal Protection Manual, Ins. Class B, Max. Ambient Temp. 40 Degrees C, Duty Cycle Continuous, Motor Shaft Rotation CW/CCW, Motor Enclosure Design Open Drip Proof, Motor Mounting Type Rigid Base, Motor Mounting Position Horizontal, Motor Frame Material Steel
Additional Information
- Country of Origin: MX
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 13.75
- Package Width: 7.88
- Package Height: 8.75
- Package Weight: 23.00
Product info last updated on March 15, 2026 11:13am UTC
Category: Motors
