Capacitor-Start General Purpose Motor, 1/3 hp HP, 115/230V AC Voltage, 48 Frame MPN:048C17D2023
Capacitor-Start General Purpose Motor, 1/3 hp HP, 115/230V AC Voltage, 48 Frame
This 1/3 hp Capacitor-Start General Purpose Motor from Leeson is a reliable and efficient solution for various applications. Suitable for use in 115/230V AC environments, it features a durable design and high performance. With a nameplate RPM of 1,725 RPM and a continuous duty cycle, it can handle demanding tasks. The motor's open drip-proof enclosure and CW/CCW shaft rotation make it ideal for use in a range of settings, including commercial and industrial environments. Its compact size and low maintenance requirements also make it a cost-effective choice for applications where reliability and efficiency are paramount.
Top product features:
- Capacitor-start design for improved starting torque and efficiency
- Single-phase motor operation for use in a variety of applications
- Open drip-proof enclosure design for protection against dust and liquid splashes
Top product applications:
- Pumps and water treatment systems
- Fans and blowers for industrial ventilation
- Conveyor belts and material handling systems
General Purpose Motor, Single Phase, Motor Design Capacitor-Start, 1/3 hp HP, Nameplate RPM 1,725 RPM, No. of Speeds 1, Voltage 115/230V AC, Full Load Amps 7.0/3.5 A, 48 Frame, Usable @ 208V Not Usable at 208V, Usable @ 200V Not Usable at 200V, Hz 60 Hz, Motor Service Factor 1, Max. Ambient Temp. 40 Degrees C, Motor Thermal Protection None, Duty Cycle Continuous, Ins. Class B, Motor Enclosure Design Open Drip Proof, Motor Shaft Rotation CW/CCW, Motor Mounting Type Rigid Base
Additional Information
- Country of Origin: MX
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 13.30
- Package Width: 8.00
- Package Height: 8.00
- Package Weight: 15.00
Product info last updated on February 22, 2026 3:10pm UTC
Category: Motors
