Capacitor-Start General Purpose Motor, 1/2 hp HP, 115/208-230V AC Voltage, 56 Frame MPN:056C17D2072
Capacitor-Start General Purpose Motor, 1/2 hp HP, 115/208-230V AC Voltage, 56 Frame
This 1/2 horsepower capacitor-start general purpose motor from Leeson is a reliable and efficient choice for a wide range of applications. Suitable for use in 115/208-230V AC environments, it offers a high level of performance and durability. With a single-phase design and 1,725 RPM, it's ideal for applications that require a moderate speed and low vibration. Its open drip-proof enclosure and cradle base mounting type make it easy to install and maintain. Perfect for use in industrial settings, this motor provides continuous duty cycle operation and meets Ins. Class B standards.
Top product features:
- Capacitor-start design for improved starting torque
- Single-phase motor operation for flexibility in applications
- Open drip-proof enclosure design for protection from dust and water
Top product applications:
- Pumps
- Fans
- Air Compressors
General Purpose Motor, Single Phase, Motor Design Capacitor-Start, 1/2 hp HP, Nameplate RPM 1,725 RPM, No. of Speeds 1, Voltage 115/208-230V AC, Full Load Amps 8.0/4.1-4.0 A, 56 Frame, Usable @ 208V Usable at 208V, Usable @ 200V Not Usable at 200V, Hz 60 Hz, Motor Service Factor 1.25, Max. Ambient Temp. 40 Degrees C, Motor Thermal Protection Auto, Duty Cycle Continuous, Ins. Class B, Motor Enclosure Design Open Drip Proof, Motor Shaft Rotation CW/CCW, Motor Mounting Type Cradle Base
Additional Information
- Country of Origin: MX
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 13.69
- Package Width: 7.31
- Package Height: 9.50
- Package Weight: 20.00
Product info last updated on February 7, 2026 2:13pm UTC
Category: Motors
