Capacitor-Start General Purpose Motor, 1/2 hp HP, 115/230V AC Voltage, 56 Frame MPN:056C17D2097
Capacitor-Start General Purpose Motor, 1/2 hp HP, 115/230V AC Voltage, 56 Frame
This 1/2 HP capacitor-start general purpose motor from Leeson is designed for a wide range of applications, including industrial and commercial use. With a nameplate RPM of 1,725, this motor provides efficient and reliable power for various processes. Its single-phase design and 115/230V AC voltage make it suitable for use in a variety of settings. The motor's open drip-proof enclosure and cradle base mounting type ensure easy installation and maintenance. Perfect for applications such as pumps, fans, and conveyors, this motor offers a cost-effective solution for businesses looking to upgrade their equipment.
Top product features:
- Capacitor-start design for efficient starting and running
- Single phase operation for simple installation and control
- Open drip-proof enclosure design for protection from dust and moisture
Top product applications:
- Pumps: suitable for use in residential and commercial applications, such as water circulation pumps and sump pumps.
- Fans: can be used in a variety of fan applications, including residential and commercial ventilation systems.
- Conveyors: can be used in small-scale conveyor systems, such as those used in packaging and material handling applications.
General Purpose Motor, Single Phase, Motor Design Capacitor-Start, 1/2 hp HP, Nameplate RPM 1,725 RPM, No. of Speeds 1, Voltage 115/230V AC, Full Load Amps 9.1/4.5 A, 56 Frame, Usable @ 208V Not Usable at 208V, Usable @ 200V Not Usable at 200V, Hz 60 Hz, Motor Service Factor 1, Max. Ambient Temp. 40 Degrees C, Motor Thermal Protection None, Duty Cycle Continuous, Ins. Class B, Motor Enclosure Design Open Drip Proof, Motor Shaft Rotation CW/CCW, Motor Mounting Type Cradle Base
Additional Information
- Country of Origin: MX
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 12.44
- Package Width: 9.13
- Package Height: 8.06
- Package Weight: 19.00
Product info last updated on February 3, 2026 6:55pm UTC
Category: Motors
