SP Motor, Split-Ph, 60 Hz, 1/4 HP MPN:048S17D2042
SP Motor, Split-Ph, 60 Hz, 1/4 HP
The Leeson SP Motor is a reliable and efficient solution for a variety of applications. This 1/4 HP, single-phase motor is designed for general purpose use and features a split-phase design for smooth operation. With a nameplate RPM of 1,725 and a voltage rating of 115V AC, this motor is suitable for use in a range of settings, including commercial and industrial environments. Its open drip-proof enclosure and continuous duty cycle make it ideal for use in areas where reliability and durability are essential. Perfect for use in fans, pumps, and other equipment, this motor provides years of trouble-free service.
Top product features:
- Split-Phase design for efficient operation
- Continuous duty cycle for extended use
- Open Drip Proof enclosure for protection against environmental factors
Top product applications:
- Pump applications for residential or commercial use
- Conveyor systems in light industry settings
- Fans and blowers in general ventilation systems
General Purpose Motor, Single Phase, Motor Design Split-Phase, 1/4 hp HP, Nameplate RPM 1,725 RPM, No. of Speeds 1, Voltage 115V AC, Full Load Amps 5.7 A, 48 Frame, Usable @ 208V Not Usable at 208V, Usable @ 200V Not Usable at 200V, Hz 60 Hz, Motor Service Factor 1, Max. Ambient Temp. 40 Degrees C, Motor Thermal Protection None, Duty Cycle Continuous, Ins. Class B, Motor Enclosure Design Open Drip Proof, Motor Shaft Rotation CW/CCW, Motor Mounting Type Cradle Base
Additional Information
- Country of Origin: MX
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 11.06
- Package Width: 6.75
- Package Height: 6.62
- Package Weight: 13.00
Product info last updated on March 2, 2026 7:24pm UTC
Category: Motors
