Capacitor-Start General Purpose Motor, 1/2 hp HP, 115/208-230V AC Voltage, 48 Frame MPN:5KC39QN3220X
Capacitor-Start General Purpose Motor, 1/2 hp HP, 115/208-230V AC Voltage, 48 Frame
This 1/2 hp capacitor-start general purpose motor from Leeson is designed for a wide range of applications, including industrial and commercial use. With a nameplate RPM of 3,450 and a voltage rating of 115/208-230V AC, it can be used in various environments. The motor's open drip-proof enclosure and cradle base mounting type make it easy to install and maintain. Its continuous duty cycle and motor thermal protection ensure reliable operation, while its 1.25 service factor and 60 Hz frequency provide added durability. Suitable for use in applications such as pumps, fans, and conveyor systems, this motor is a versatile and reliable choice.
Top product features:
- Capacitor-start design for improved starting torque and efficiency
- Single-phase operation for a wide range of applications
- Open drip-proof enclosure design for protection from dust and moisture
Top product applications:
- Industrial machinery
- Pumps and water treatment systems
- Conveyor belts and material handling equipment
General Purpose Motor, Single Phase, Motor Design Capacitor-Start, 1/2 hp HP, Nameplate RPM 3,450 RPM, No. of Speeds 1, Voltage 115/208-230V AC, Full Load Amps 8.2/4.1-3.9 A, 48 Frame, Usable @ 208V Usable at 208V, Usable @ 200V Not Usable at 200V, Hz 60 Hz, Motor Service Factor 1.25, Max. Ambient Temp. 40 Degrees C, Motor Thermal Protection Auto, Duty Cycle Continuous, Ins. Class B, Motor Enclosure Design Open Drip Proof, Motor Shaft Rotation CW/CCW, Motor Mounting Type Cradle Base
Additional Information
- Country of Origin: MX
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 15.44
- Package Width: 10.19
- Package Height: 9.50
- Package Weight: 19.00
Product info last updated on February 11, 2026 10:26am UTC
Category: Motors
