Capacitor-Start General Purpose Motor, 1/2 hp HP, 115/230V AC Voltage, 56 Frame MPN:056C17D2098
Capacitor-Start General Purpose Motor, 1/2 hp HP, 115/230V AC Voltage, 56 Frame
This 1/2 hp capacitor-start general purpose motor from Leeson is a reliable and efficient solution for various applications. Suitable for use in 115/230V AC environments, it offers a single speed operation at 1,725 RPM, making it ideal for applications that require consistent torque and speed. The motor's open drip-proof enclosure design provides protection against dust and water, while its rigid base mounting type ensures secure installation. With a continuous duty cycle and a maximum ambient temperature of 40°C, this motor is perfect for use in industrial settings, including manufacturing, HVAC, and material handling systems.
Top product features:
- Capacitor-start design for improved starting torque and efficiency
- Single-phase operation for simplified installation and control
- Open drip-proof enclosure design for protection against dust and water spray
Top product applications:
- Pumps
- Conveyors
- Fans
General Purpose Motor, Single Phase, Motor Design Capacitor-Start, 1/2 hp HP, Nameplate RPM 1,725 RPM, No. of Speeds 1, Voltage 115/230V AC, Full Load Amps 9.1/4.5 A, 56 Frame, Usable @ 208V Not Usable at 208V, Usable @ 200V Not Usable at 200V, Hz 60 Hz, Motor Service Factor 1, Max. Ambient Temp. 40 Degrees C, Motor Thermal Protection None, Duty Cycle Continuous, Ins. Class B, Motor Enclosure Design Open Drip Proof, Motor Shaft Rotation CW/CCW, Motor Mounting Type Rigid Base
Additional Information
- Country of Origin: MX
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 12.44
- Package Width: 9.13
- Package Height: 8.06
- Package Weight: 18.00
Product info last updated on February 20, 2026 7:46am UTC
Category: Motors
