Three-Phase General Purpose Motor, 3/4 HP, 56HC Frame, 208-230/460V Voltage, 1, 725 Nameplate RPM
This 3/4 HP three-phase general purpose motor from Leeson is designed for a wide range of applications, including industrial and commercial use. Its 56HC frame and open drip-proof motor enclosure provide reliable operation in various environments. The motor's high nameplate RPM of 1,725 and high efficiency of 81.1 percent make it suitable for applications requiring high speed and power. Suitable for use in HVAC systems, conveyor belts, and other industrial equipment, this motor offers a cost-effective solution for demanding applications, with a service factor of 1.25 and a maximum ambient temperature of 40°C.
Top product features:
- Three-phase operation for efficient power distribution
- Open drip-proof motor enclosure design for protection against dust and moisture
- Ball motor bearings for smooth and quiet operation
Top product applications:
- Pumps
- Fans
- Conveyors
General Purpose Motor, Three-Phase, Open Drip Proof Motor Enclosure Design, 3/4 HP, Nameplate RPM 1,725, Frame 56HC, Voltage 208-230/460V, 60 Hz Hz, Three Phase, Full Load Amps 2.6/1.3 A, Universal Motor Mounting Type, Motor Thermal Protection None, Ins. Class F, Motor Service Factor 1.25, Ball Motor Bearings, Motor Frame Material Steel, Max. Ambient Temp. 40 Degrees C, CCW/CW Motor Shaft Rotation, Nominal Efficiency 81.1 Percent, 0-1,725, CE, CSA, UL
Additional Information
- Country of Origin: MX
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 16.12
- Package Width: 10.25
- Package Height: 8.12
- Package Weight: 30.00
