Capacitor-Start General Purpose Motor, 1 hp HP, 115/230V AC Voltage, 56 Frame MPN:056C17D5340
Capacitor-Start General Purpose Motor, 1 hp HP, 115/230V AC Voltage, 56 Frame
This 1 hp General Purpose Motor from Leeson is a reliable and efficient choice for various applications. Suitable for single-phase 115/230V AC voltage, it offers a nameplate RPM of 1,725 and a continuous duty cycle. The capacitor-start design ensures optimal performance and energy efficiency. With a 56 frame size and a maximum ambient temperature of 40 Degrees C, this motor is ideal for use in various environments. Its open drip-proof enclosure design and cradle base mounting type make it easy to install and maintain. Perfect for use in commercial and industrial settings, this motor is a great value for its price.
Top product features:
- Capacitor-start design for efficient motor operation
- Single-phase motor design for versatile application
- Open drip-proof enclosure for protection from dust and debris
Top product applications:
- Pumps and water treatment systems
- Fans and blowers
- Conveyors and material handling equipment
General Purpose Motor, Single Phase, Motor Design Capacitor-Start, 1 hp HP, Nameplate RPM 1,725 RPM, No. of Speeds 1, Voltage 115/230V AC, Full Load Amps 13.6/6.8 A, 56 Frame, Usable @ 208V Not Usable at 208V, Usable @ 200V Not Usable at 200V, Hz 60 Hz, Motor Service Factor 1, Max. Ambient Temp. 40 Degrees C, Motor Thermal Protection Auto, Duty Cycle Continuous, Ins. Class B, Motor Enclosure Design Open Drip Proof, Motor Shaft Rotation CW/CCW, Motor Mounting Type Cradle Base
Additional Information
- Country of Origin: MX
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 13.25
- Package Width: 9.62
- Package Height: 7.75
- Package Weight: 29.00
Product info last updated on February 5, 2026 6:32pm UTC
Category: Motors
