Capacitor-Start General Purpose Motor, 1/4 hp HP, 115/230V AC Voltage, 48 Frame MPN:5KC35JN7X
Capacitor-Start General Purpose Motor, 1/4 hp HP, 115/230V AC Voltage, 48 Frame
This 1/4 hp capacitor-start general purpose motor from Leeson is designed for a wide range of applications, including industrial and commercial settings. With a single-phase design and 115/230V AC voltage, it's suitable for use in various environments. The motor features a high service factor of 1.35, allowing for continuous operation at maximum efficiency. Its open drip-proof enclosure and cradle base mounting type make it easy to install and maintain. Ideal for use in applications such as pumps, fans, and conveyors, this motor provides reliable performance and long-lasting durability.
Top product features:
- Capacitor-start design for efficient starting and running
- Single-phase motor operation for simple installation and control
- Open drip-proof enclosure design for protection against dust and moisture
Top product applications:
- Pumps
- Fans
- Compressors
General Purpose Motor, Single Phase, Motor Design Capacitor-Start, 1/4 hp HP, Nameplate RPM 1,725 RPM, No. of Speeds 1, Voltage 115/230V AC, Full Load Amps 5.2/2.6 A, 48 Frame, Usable @ 208V Not Usable at 208V, Usable @ 200V Not Usable at 200V, Hz 60 Hz, Motor Service Factor 1.35, Max. Ambient Temp. 40 Degrees C, Motor Thermal Protection Auto, Duty Cycle Continuous, Ins. Class B, Motor Enclosure Design Open Drip Proof, Motor Shaft Rotation CW/CCW, Motor Mounting Type Cradle Base
Additional Information
- Country of Origin: MX
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 12.63
- Package Width: 6.94
- Package Height: 7.50
- Package Weight: 16.00
Product info last updated on February 20, 2026 1:06am UTC
Category: Motors
