SP Motor, Split-Ph, 1/2 HP, 60 Hz MPN:056S17D2046
SP Motor, Split-Ph, 1/2 HP, 60 Hz
This 1/2 HP Leeson SP Motor is a reliable and efficient general-purpose motor designed for single-phase applications. Suitable for use in a variety of settings, including industrial and commercial environments, this motor operates at 1,725 RPM and is rated for continuous duty cycles. Its open drip-proof enclosure provides protection from dust and water, making it ideal for use in harsh conditions. With a compact design and rugged construction, this motor is perfect for applications such as pumps, fans, and conveyors, offering a cost-effective solution for businesses seeking reliable and efficient motor performance.
Top product features:
- Split-Phase motor design for efficient and reliable operation
- Continuous duty cycle for uninterrupted performance
- Open Drip Proof motor enclosure for protection against dust and moisture
Top product applications:
- Pump applications
- Conveyor system
- Fans and blowers
General Purpose Motor, Single Phase, Motor Design Split-Phase, 1/2 hp HP, Nameplate RPM 1,725 RPM, No. of Speeds 1, Voltage 115V AC, Full Load Amps 9.2 A, 56 Frame, Usable @ 208V Not Usable at 208V, Usable @ 200V Not Usable at 200V, Hz 60 Hz, Motor Service Factor 1, Max. Ambient Temp. 40 Degrees C, Motor Thermal Protection None, Duty Cycle Continuous, Ins. Class B, Motor Enclosure Design Open Drip Proof, Motor Shaft Rotation CW/CCW, Motor Mounting Type Rigid Base
Additional Information
- Country of Origin: MX
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 11.50
- Package Width: 7.20
- Package Height: 7.50
- Package Weight: 17.35
Product info last updated on February 23, 2026 10:48am UTC
Category: Motors
