Capacitor-Start General Purpose Motor, 1 hp HP, 115/208-230V AC Voltage, 56 Frame MPN:5KC39RN383X
Capacitor-Start General Purpose Motor, 1 hp HP, 115/208-230V AC Voltage, 56 Frame
The Leeson Capacitor-Start General Purpose Motor is a reliable and efficient solution for a variety of applications. This 1 hp motor is designed for single-phase use and is suitable for 115/208-230V AC voltage. Its capacitor-start design provides a high starting torque, making it ideal for pumps, fans, and other equipment that require a strong initial push. With a 3,450 RPM nameplate speed and a 1.25 service factor, this motor can handle continuous duty cycles in temperatures up to 40°C. Its open drip-proof enclosure and cradle base mounting make it easy to install and maintain, making it a great choice for industrial and commercial settings.
Top product features:
- Capacitor-start design for improved starting torque
- Single-phase motor operation for simple installation
- Open drip-proof motor enclosure design for protection against dust and water splashes
Top product applications:
- Industrial pumps and machinery
- Food processing equipment
- Textile manufacturing machinery
General Purpose Motor, Single Phase, Motor Design Capacitor-Start, 1 hp HP, Nameplate RPM 3,450 RPM, No. of Speeds 1, Voltage 115/208-230V AC, Full Load Amps 13.4/6.7-6.6 A, 56 Frame, Usable @ 208V Usable at 208V, Usable @ 200V Not Usable at 200V, Hz 60 Hz, Motor Service Factor 1.25, Max. Ambient Temp. 40 Degrees C, Motor Thermal Protection Auto, Duty Cycle Continuous, Ins. Class B, Motor Enclosure Design Open Drip Proof, Motor Shaft Rotation CW/CCW, Motor Mounting Type Cradle Base
Additional Information
- Country of Origin: ZZ
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 13.69
- Package Width: 7.13
- Package Height: 7.50
- Package Weight: 25.00
Product info last updated on January 19, 2026 9:37pm UTC
Category: Motors
