Three-Phase General Purpose Motor, 1 1/2 HP, 145TC Frame, 230/460V AC Voltage MPN:145TTFR6058
Three-Phase General Purpose Motor, 1 1/2 HP, 145TC Frame, 230/460V AC Voltage
This three-phase general purpose motor from Leeson is designed for a wide range of applications, including industrial and commercial use. With a 1 1/2 HP rating and 1755 rpm, it provides reliable and efficient power for machinery and equipment. The totally enclosed fan cooled motor enclosure design ensures durability and protection in harsh environments. Suitable for continuous duty, this motor is ideal for applications such as pumps, fans, and conveyor systems. Its high efficiency and robust construction make it a reliable choice for demanding industrial settings.
Top product features:
- Totally Enclosed Fan Cooled Motor Enclosure Design
- Ball Motor Bearings
- Continuous Duty Operation
Top product applications:
- Industrial machinery
- Manufacturing equipment
- Pumps and compressors
General Purpose Motor, Three-Phase, Totally Enclosed Fan Cooled Motor Enclosure Design, 1 1/2 HP, Nameplate RPM 1755 rpm, Frame 145TC, Voltage 230/460V AC, 60/50 Hz Hz, Three Phase, Full Load Amps 4.6/2.3 A, Rigid Base Motor Mounting Type, Motor Thermal Protection None, Ins. Class F, Motor Service Factor 1.15, Ball Motor Bearings, Motor Frame Material Steel, Max. Ambient Temp. 40 Degrees C, CW/CCW Motor Shaft Rotation, Nominal Efficiency 86.5 Percent, Continuous Duty, 1701-1800
Additional Information
- Country of Origin: MX
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 16.38
- Package Width: 10.50
- Package Height: 8.12
- Package Weight: 44.00
Product info last updated on March 2, 2026 4:41am UTC
Category: Motors
