Capacitor-Start/Run General Purpose Motor, 1 1/2 hp HP, 115/208-230V AC Voltage, 56 Frame MPN:056B34D2027
Capacitor-Start/Run General Purpose Motor, 1 1/2 hp HP, 115/208-230V AC Voltage, 56 Frame
This 1.5 hp capacitor-start/run motor from Leeson is a versatile and reliable choice for a wide range of applications, including industrial and commercial settings. Its single-phase design and 3,450 RPM nameplate speed make it suitable for use in various equipment and machinery. With a service factor of 1.15 and continuous duty cycle, this motor can handle demanding tasks with ease. Its open drip-proof enclosure and cradle base mounting type make it easy to install and maintain. Additionally, its compact size and lightweight design make it ideal for applications where space is limited.
Top product features:
- Capacitor-start/run design for improved starting torque and efficiency
- Single-phase motor operation for easy installation and connection
- Continuous duty cycle for reliable operation in demanding applications
Top product applications:
- Pumps
- Fans
- Air Compressors
General Purpose Motor, Single Phase, Motor Design Capacitor-Start/Run, 1 1/2 hp HP, Nameplate RPM 3,450 RPM, No. of Speeds 1, Voltage 115/208-230V AC, Full Load Amps 13.0/7.4-6.5 A, 56 Frame, Usable @ 208V Usable at 208V, Usable @ 200V Not Usable at 200V, Hz 60 Hz, Motor Service Factor 1.15, Max. Ambient Temp. 40 Degrees C, Motor Thermal Protection Auto, Duty Cycle Continuous, Ins. Class B, Motor Enclosure Design Open Drip Proof, Motor Shaft Rotation CW/CCW, Motor Mounting Type Cradle Base
Additional Information
- Country of Origin: MX
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 13.75
- Package Width: 7.88
- Package Height: 8.75
- Package Weight: 28.00
Product info last updated on February 3, 2026 6:16am UTC
Category: Motors
