Capacitor-Start General Purpose Motor, 3/4 hp HP, 115/208-230V AC Voltage, 56 Frame MPN:5KC46JN0002X
Capacitor-Start General Purpose Motor, 3/4 hp HP, 115/208-230V AC Voltage, 56 Frame
This 3/4 hp Capacitor-Start General Purpose Motor from Leeson is a reliable and efficient solution for a variety of applications. Suitable for use in 115/208-230V AC environments, this motor is perfect for industrial settings, commercial facilities, and even residential areas. With a continuous duty cycle and a motor service factor of 1.25, it can handle demanding tasks with ease. The open drip-proof design and CW/CCW rotation ensure smooth operation and versatility. Ideal for use in fans, pumps, and other machinery, this motor provides long-lasting performance and minimal maintenance requirements, making it a great addition to any facility.
Top product features:
- Capacitor-start design provides efficient starting and running of the motor
- Single-phase motor operation allows for use in a variety of applications
- Open drip-proof motor enclosure design protects the motor from dust and water
Top product applications:
- Industrial Pump
- Water Treatment Plant
- Conveyor System
General Purpose Motor, Single Phase, Motor Design Capacitor-Start, 3/4 hp HP, Nameplate RPM 1,725 RPM, No. of Speeds 1, Voltage 115/208-230V AC, Full Load Amps 11.4/5.7-5.6 A, 56 Frame, Usable @ 208V Usable at 208V, Usable @ 200V Not Usable at 200V, Hz 60 Hz, Motor Service Factor 1.25, Max. Ambient Temp. 40 Degrees C, Motor Thermal Protection Auto, Duty Cycle Continuous, Ins. Class B, Motor Enclosure Design Open Drip Proof, Motor Shaft Rotation CW/CCW, Motor Mounting Type Cradle Base
Additional Information
- Country of Origin: ZZ
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 13.69
- Package Width: 7.13
- Package Height: 7.50
- Package Weight: 23.00
Product info last updated on March 22, 2026 2:57am UTC
Category: Motors
