Capacitor-Start General Purpose Motor, 1 hp HP, 115/208-230V AC Voltage, 56 Frame MPN:056C34D2106
Capacitor-Start General Purpose Motor, 1 hp HP, 115/208-230V AC Voltage, 56 Frame
The Leeson Capacitor-Start General Purpose Motor is a reliable and efficient solution for a wide range of applications. Suitable for use in environments up to 40°C, this motor can handle continuous duty cycles and is designed to provide long-lasting performance. With a single-phase design and 1 hp output, it's perfect for small to medium-sized industrial equipment, including fans, pumps, and conveyor systems. Its compact 56 frame size and open drip-proof enclosure make it easy to install and maintain. Available in 115/208-230V AC voltage, this motor is a versatile and cost-effective choice for many industries.
Top product features:
- Capacitor-start design for efficient starting and reduced wear on the motor
- Single-phase operation for compatibility with standard household electrical systems
- Open drip-proof enclosure for protection from dust and water in harsh environments
Top product applications:
- Pumps
- Fans
- Conveyors
General Purpose Motor, Single Phase, Motor Design Capacitor-Start, 1 hp HP, Nameplate RPM 3,450 RPM, No. of Speeds 1, Voltage 115/208-230V AC, Full Load Amps 12.0/6.2-6.0 A, 56 Frame, Usable @ 208V Usable at 208V, Usable @ 200V Not Usable at 200V, Hz 60 Hz, Motor Service Factor 1.15, Max. Ambient Temp. 40 Degrees C, Motor Thermal Protection Auto, Duty Cycle Continuous, Ins. Class B, Motor Enclosure Design Open Drip Proof, Motor Shaft Rotation CW/CCW, Motor Mounting Type Cradle Base
Additional Information
- Country of Origin: MX
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 13.75
- Package Width: 7.88
- Package Height: 8.75
- Package Weight: 25.00
Product info last updated on March 4, 2026 10:08am UTC
Category: Motors
