Vector Motor, 3/4 HP, 2.28 ft.-lb., 230V MPN:056H17F2011
Vector Motor, 3/4 HP, 2.28 ft.-lb., 230V
This 3/4 HP three-phase motor from Leeson is designed for heavy-duty applications that require reliable performance and efficiency. Its 2.28 ft-lb torque and 1,725 nameplate RPM make it suitable for use in industrial settings, such as conveyor systems, pumps, and machinery. The motor's continuous duty cycle and 1,000:1 speed range provide flexibility and versatility. With a compact 56C frame and Class H insulation, it can operate in temperatures up to 104°F, making it ideal for use in manufacturing facilities, warehouses, and other high-temperature environments. Its durable design ensures long-lasting performance and minimal maintenance.
Top product features:
- Three Phase Design
- High Torque Output of 2.28 ft-lb
- Speed Range of 1,000:1
Top product applications:
- Pumps
- Conveyors
- Fans
Vector Motor, Three Phase, Motor Design 3-Phase, 3/4 HP, Nameplate RPM 1,725, No. of Speeds 1, Voltage 230V AC, Full Load Amps 2.8 A, 56C Frame, Torque 2.28 ft-lb, Max. Speed 5,400 RPM, Speed Range 1,000:1, Usable @ 208V No, Usable @ 200V No, 60 Hz Hz, Max. Operating Frequency 120 Hz, Motor Service Factor 1, Motor Thermal Protection None, Ins. Class H, Max. Ambient Temp. 104 Degrees F, Duty Cycle Continuous, NEMA Design B, Motor Shaft Rotation CW/CCW
Additional Information
- Country of Origin: ZZ
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 15 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 12.44
- Package Width: 9.13
- Package Height: 8.06
- Package Weight: 22.00
