Capacitor-Start General Purpose Motor, 1/3 hp HP, 115/208-230V AC Voltage, 48 Frame MPN:5KC36LN26X
Capacitor-Start General Purpose Motor, 1/3 hp HP, 115/208-230V AC Voltage, 48 Frame
This 1/3 hp Capacitor-Start General Purpose Motor from Leeson is a reliable and efficient solution for various applications. Suitable for use in 115/208-230V AC voltage environments, it features a 1,725 RPM nameplate speed and a 6.0/3.2-3.0 A full load amp rating. The motor's open drip-proof design and cradle base mounting type make it ideal for use in a variety of settings, including industrial and commercial environments. With a continuous duty cycle and motor thermal protection, this motor provides reliable operation and extended lifespan. Its compact design and ease of installation make it a convenient choice for applications where space is limited.
Top product features:
- Capacitor-start design for improved starting torque and efficiency
- Single-phase operation for simplified installation and control
- Open drip-proof enclosure for protection against dust and water ingress
Top product applications:
- Pumps and fans
- Air compressors
- Conveyor systems
General Purpose Motor, Single Phase, Motor Design Capacitor-Start, 1/3 hp HP, Nameplate RPM 1,725 RPM, No. of Speeds 1, Voltage 115/208-230V AC, Full Load Amps 6.0/3.2-3.0 A, 48 Frame, Usable @ 208V Usable at 208V, Usable @ 200V Not Usable at 200V, Hz 60/50 Hz, Motor Service Factor 1.35, Max. Ambient Temp. 40 Degrees C, Motor Thermal Protection Auto, Duty Cycle Continuous, Ins. Class B, Motor Enclosure Design Open Drip Proof, Motor Shaft Rotation CW/CCW, Motor Mounting Type Cradle Base
Additional Information
- Country of Origin: ZZ
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 12.63
- Package Width: 6.94
- Package Height: 7.50
- Package Weight: 18.00
Product info last updated on February 3, 2026 6:32pm UTC
Category: Motors
