General Purpose Farm Duty Motor, Split-Phase, 1/4, 1/12 HP, 115V AC, 1, 725/1, 140 Nameplate RPM MPN:048S17T366
General Purpose Farm Duty Motor, Split-Phase, 1/4, 1/12 HP, 115V AC, 1, 725/1, 140 Nameplate RPM
This Leeson General Purpose Farm Duty Motor is a reliable and efficient solution for a variety of agricultural applications. With a split-phase design and 1/4 or 1/2 horsepower options, it can handle demanding tasks with ease. Suitable for use in 115V AC environments, this motor features a continuous duty cycle and can operate in temperatures up to 40 degrees C. Its totally enclosed air-over design protects against dust and moisture, making it ideal for outdoor use. Perfect for powering pumps, irrigation systems, and other farm equipment, this motor provides a durable and cost-effective solution for your agricultural needs.
Top product features:
- Totally Enclosed Air-Over Motor Enclosure Design for protection from dust and debris
- Continuous Duty Cycle for extended operation without overheating
- Auto Thermal Protection for safe shutdown in case of overheating
Top product applications:
- Pumps for irrigation systems
- Power tools for farm equipment maintenance
- Fans for ventilation in farm buildings
Farm Duty Motor, Single Phase, Motor Design Split-Phase, 1/2 hp, 1/4 hp HP, Nameplate RPM 1,725/1140 RPM, No. of Speeds 2, Voltage 115V AC, Full Load Amps 3.9/2.2 A, 48 Frame, Usable @ 208V Not Usable at 208V, Usable @ 200V Not Usable at 200V, 60 Hz Hz, Motor Service Factor 1, Motor Thermal Protection Auto, Ins. Class B, Max. Ambient Temp. 40 Degrees C, Duty Cycle Continuous, Motor Shaft Rotation CW/CCW, Motor Enclosure Design Totally Enclosed Air-Over, Motor Mounting Type Stud
Additional Information
- Country of Origin: ZZ
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 13.25
- Package Width: 7.00
- Package Height: 6.94
- Package Weight: 17.00
Product info last updated on February 3, 2026 5:58pm UTC
Category: Motors
