Permanent Split Capacitor General Purpose Farm Duty Motor, 1/3 HP, 48Z Frame, 115/230V AC Voltage MPN:048A17T2003
Permanent Split Capacitor General Purpose Farm Duty Motor, 1/3 HP, 48Z Frame, 115/230V AC Voltage
This 1/3 HP Leeson Farm Duty Motor is designed for general-purpose applications on farms and in rural areas. With a permanent split capacitor design and 1,625 RPM, it provides reliable and efficient power for a variety of tasks. Suitable for use with 115/230V AC voltage, it can handle continuous duty cycles in temperatures up to 40°C. The totally enclosed air-over design protects against dust and moisture, making it ideal for use in harsh environments. Perfect for powering pumps, water tanks, and other equipment, this motor is a reliable choice for farmers and rural residents.
Top product features:
- Permanent Split Capacitor motor design
- Totally Enclosed Air-Over motor enclosure design
- Continuous duty cycle operation
Top product applications:
- Pump and irrigation systems for agricultural use
- Well pumps and water supply systems for rural areas
- Small to medium-sized industrial equipment, such as conveyors and mixers
Farm Duty Motor, Single Phase, Motor Design Permanent Split Capacitor, 1/3 hp HP, Nameplate RPM 1,625 RPM, No. of Speeds 1, Voltage 115/230V AC, Full Load Amps 4.2/2.1 A, 48Z Frame, Usable @ 208V Not Usable at 208V, Usable @ 200V Not Usable at 200V, 60 Hz Hz, Motor Service Factor 1, Motor Thermal Protection Auto, Ins. Class B, Max. Ambient Temp. 40 Degrees C, Duty Cycle Continuous, Motor Shaft Rotation CW/CCW, Motor Enclosure Design Totally Enclosed Air-Over, Motor Mounting Type Cradle Base
Additional Information
- Country of Origin: MX
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 12.44
- Package Width: 9.13
- Package Height: 8.06
- Package Weight: 18.00
