Capacitor-Start/Run Belt Drive Motor, 1/2 HP, 56 Frame, 115/230V AC Voltage, 1, 725 Nameplate RPM MPN:056B17T20
Capacitor-Start/Run Belt Drive Motor, 1/2 HP, 56 Frame, 115/230V AC Voltage, 1, 725 Nameplate RPM
This 1/2 HP, 115/230V AC voltage, capacitor-start/run belt drive motor from Leeson is designed for single-phase applications. It operates at 1,725 nameplate RPM, providing efficient and reliable performance. The motor features a rigid base mounting type, totally enclosed air-over design, and automatic thermal protection, ensuring safe and continuous operation. Suitable for use in a variety of settings, including fans and blowers, it offers a cost-effective solution for applications requiring high airflow and reliability. Its compact size and lightweight design make it easy to integrate into new or existing systems, providing a reliable and efficient solution for demanding applications.
Top product features:
- Capacitor-start/run design for efficient motor operation
- Totally enclosed air-over motor enclosure for protection against dust and moisture
- Continuous duty cycle for long-term operation without overheating
Top product applications:
- HVAC systems
- Industrial ventilation systems
- Pumps and water treatment systems
Fan and Blower Motor, Single Phase, Motor Design Capacitor-Start/Run, 1/2 hp HP, Nameplate RPM 1,725 RPM, No. of Speeds 1, Voltage 115/230V AC, 4.6/2.3 A Full Load Amps, 56 Frame, 60 Hz Hz, Usable @ 208V Not Usable at 208V, Usable @ 200V Not Usable at 200V, Motor Service Factor 1, Motor Thermal Protection Auto, Ins. Class B, Duty Cycle Continuous, Max. Ambient Temp. 40 Degrees C, Motor Shaft Rotation CW/CCW, Motor Enclosure Design Totally Enclosed Air-Over, Motor Mounting Type Rigid Base
Additional Information
- Country of Origin: MX
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 12.75
- Package Width: 9.50
- Package Height: 9.38
- Package Weight: 22.00
Product info last updated on February 3, 2026 4:19pm UTC
Category: Motors
