Capacitor-Start General Purpose Motor, 1 hp HP, 115/230V AC Voltage, 56 Frame MPN:5KC49NN2130X
Capacitor-Start General Purpose Motor, 1 hp HP, 115/230V AC Voltage, 56 Frame
This 1 hp General Purpose Motor from Leeson is a reliable and efficient solution for a wide range of applications. Suitable for use in single-phase systems, it offers a high level of performance and durability. With a capacitor-start design and totally enclosed fan-cooled enclosure, it can operate in demanding environments while minimizing maintenance needs. The motor is also designed for continuous duty cycles, making it ideal for applications where high uptime is critical. Its compact size and rugged construction make it a versatile choice for various industries and applications, including manufacturing, construction, and more.
Top product features:
- Capacitor-start design for improved motor efficiency
- Totally enclosed fan-cooled design for reduced heat and increased reliability
- Continuous duty cycle for uninterrupted operation
Top product applications:
- Pumps and blowers in commercial and industrial settings
- Fans and blowers in HVAC systems
- Conveyors and material handling equipment in manufacturing
General Purpose Motor, Single Phase, Motor Design Capacitor-Start, 1 hp HP, Nameplate RPM 3,450 RPM, No. of Speeds 1, Voltage 115/230V AC, Full Load Amps 13.0/6.5 A, 56 Frame, Usable @ 208V Not Usable at 208V, Usable @ 200V Not Usable at 200V, Hz 60 Hz, Motor Service Factor 1.15, Max. Ambient Temp. 40 Degrees C, Motor Thermal Protection Auto, Duty Cycle Continuous, Ins. Class B, Motor Enclosure Design Totally Enclosed Fan Cooled, Motor Shaft Rotation CW/CCW, Motor Mounting Type Rigid Base
Additional Information
- Country of Origin: ZZ
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 15.14
- Package Width: 10.19
- Package Height: 9.50
- Package Weight: 29.00
Product info last updated on February 6, 2026 12:59am UTC
Category: Motors
