General Purpose Farm Duty Motor, Capacitor-Start/Run, 1 HP, 115/208-230V AC, 1, 725 Nameplate RPM MPN:5KCR49SN0042S
General Purpose Farm Duty Motor, Capacitor-Start/Run, 1 HP, 115/208-230V AC, 1, 725 Nameplate RPM
This General Purpose Farm Duty Motor from Leeson is designed for heavy-duty applications, providing reliable performance and long-lasting durability. With a 1 HP capacity and 1,725 Nameplate RPM, it's ideal for powering farm equipment, irrigation systems, and other agricultural machinery. The capacitor-start/run design ensures efficient operation, while the totally enclosed non-ventilated (TENV) enclosure protects against dust and moisture. Suitable for continuous duty cycles, this motor can withstand the rigors of farm work, making it a valuable addition to any agricultural operation. Its compact size and lightweight design also make it easy to install and maintain.
Top product features:
- Capacitor-start/run design for efficient and reliable operation
- Totally enclosed non-ventilated enclosure for dust and moisture protection
- Continuous duty cycle for long-term operation without overheating
Top product applications:
- Pump for irrigation systems
- Fan for grain drying applications
- Well pump for rural water supply
Farm Duty Motor, Single Phase, Motor Design Capacitor-Start/Run, 1 hp HP, Nameplate RPM 1,725 RPM, No. of Speeds 1, Voltage 115/208-230V AC, Full Load Amps 9.6/5.2-4.8 A, 56 Frame, Usable @ 208V Usable at 208V, Usable @ 200V Not Usable at 200V, 60 Hz Hz, Motor Service Factor 1.3, Motor Thermal Protection Auto, Ins. Class B, Max. Ambient Temp. 40 Degrees C, Duty Cycle Continuous, Motor Shaft Rotation CW/CCW, Motor Enclosure Design Totally Enclosed Non-Ventilated, Motor Mounting Type Cradle Base
Additional Information
- Country of Origin: ZZ
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 15.63
- Package Width: 9.88
- Package Height: 7.50
- Package Weight: 35.00
Product info last updated on February 8, 2026 11:29am UTC
Category: Motors
