General Purpose Farm Duty Motor, Split-Phase, 1/3, 1/8 HP, 115V AC, 1, 725/1, 150 Nameplate RPM MPN:048S17T365
General Purpose Farm Duty Motor, Split-Phase, 1/3, 1/8 HP, 115V AC, 1, 725/1, 150 Nameplate RPM
The Leeson General Purpose Farm Duty Motor is a reliable and efficient solution for a variety of agricultural and industrial applications. Designed for continuous use in harsh environments, this single-phase motor operates at 1,725/1,150 RPM and is available in 1/3 and 1/8 HP options. With a totally enclosed air-over design and CW/CCW rotation, it provides protection against dust and moisture. The motor's compact size and lightweight design make it easy to install and maintain. Suitable for use in farm equipment, generators, and other applications requiring a rugged and dependable motor, the Leeson Farm Duty Motor is a valuable addition to any operation.
Top product features:
- Totally Enclosed Air-Over Motor Enclosure Design
- Motor Shaft Rotation CW/CCW
- Continuous Duty Cycle Capability
Top product applications:
- Pumps
- Fans
- Generators
Farm Duty Motor, Single Phase, Motor Design Split-Phase, 1/3 hp, 1/8 hp HP, Nameplate RPM 1,725/1,150 RPM, No. of Speeds 2, Voltage 115V AC, Full Load Amps 5.3/2.9 A, 48Y Frame, Usable @ 208V Not Usable at 208V, Usable @ 200V Not Usable at 200V, 60 Hz Hz, Motor Service Factor 1, Motor Thermal Protection Auto, Ins. Class B, Max. Ambient Temp. 40 Degrees C, Duty Cycle Continuous, Motor Shaft Rotation CW/CCW, Motor Enclosure Design Totally Enclosed Air-Over, Motor Mounting Type Stud
Additional Information
- Country of Origin: ZZ
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 13.25
- Package Width: 7.00
- Package Height: 6.94
- Package Weight: 18.00
