Capacitor-Start General Purpose Motor, 1 hp HP, 115/230V AC Voltage, 56 Frame MPN:5KC49TN0034X
Capacitor-Start General Purpose Motor, 1 hp HP, 115/230V AC Voltage, 56 Frame
This 1 hp Capacitor-Start General Purpose Motor from Leeson is a reliable and efficient solution for a wide range of applications. Suitable for use in 115/230V AC environments, it operates at 1,725 RPM and features a rigid base mounting type. The motor's totally enclosed fan-cooled design ensures optimal performance and protection in harsh conditions. Its continuous duty cycle and auto thermal protection make it ideal for applications requiring high reliability. Perfect for industrial settings, the motor is also suitable for use in commercial settings where high efficiency is crucial. Its compact size and robust design make it a versatile choice.
Top product features:
- Capacitor-start design for efficient operation
- Totally enclosed fan-cooled motor for reliable performance in harsh environments
- Continuous duty cycle for uninterrupted operation
Top product applications:
- Pumps
- Fans
- Conveyors
General Purpose Motor, Single Phase, Motor Design Capacitor-Start, 1 hp HP, Nameplate RPM 1,725 RPM, No. of Speeds 1, Voltage 115/230V AC, Full Load Amps 13.2/6.6 A, 56 Frame, Usable @ 208V Not Usable at 208V, Usable @ 200V Not Usable at 200V, Hz 60 Hz, Motor Service Factor 1, Max. Ambient Temp. 40 Degrees C, Motor Thermal Protection Auto, Duty Cycle Continuous, Ins. Class B, Motor Enclosure Design Totally Enclosed Fan Cooled, Motor Shaft Rotation CW/CCW, Motor Mounting Type Rigid Base
Additional Information
- Country of Origin: ZZ
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 15.14
- Package Width: 10.19
- Package Height: 9.50
- Package Weight: 36.00
Product info last updated on February 15, 2026 5:49pm UTC
Category: Motors
