Vector Motor, 1/2 HP, 1.52 lb-ft, 230/460V MPN:056H17T5301
Vector Motor, 1/2 HP, 1.52 lb-ft, 230/460V
The Leeson Vector Motor is a high-performance, 1/2 HP, three-phase motor designed for a wide range of applications. With a nameplate RPM of 1,735 and a speed range of 1,000:1, this motor delivers efficient and reliable operation in various settings. Its 1.52 lb-ft of torque and 5,400 RPM make it suitable for applications requiring moderate to high-speed operation. The motor is built to withstand demanding conditions, with a maximum ambient temperature of 104°F and a continuous duty cycle. Ideal for use in industrial, commercial, and manufacturing environments, this motor provides a cost-effective solution for applications such as pumps, fans, and conveyors.
Top product features:
- Three-phase design
- Continuous duty cycle
- Speed range of 1,000:1
Top product applications:
- Pumps
- Fans
- Conveyors
Vector Motor, Three Phase, Motor Design Three-Phase, 1/2 HP, Nameplate RPM 1,735, No. of Speeds 1, Voltage 230/460V AC, Full Load Amps 1.6/0.80 A, 56C Frame, Torque 1.52 ft-lb, Max. Speed 5,400 RPM, Speed Range 1,000:1, Usable @ 208V Not Usable at 208V, Usable @ 200V Not Usable at 200V, 60 Hz Hz, Max. Operating Frequency 120 Hz, Motor Service Factor 1, Motor Thermal Protection None, Ins. Class F, Max. Ambient Temp. 104 Degrees F, Duty Cycle Continuous, NEMA Design A, Motor Shaft Rotation CW/CCW
Additional Information
- Country of Origin: ZZ
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 16.38
- Package Width: 10.50
- Package Height: 8.12
- Package Weight: 27.00
Product info last updated on February 24, 2026 10:30am UTC
Category: Motors
