Capacitor-Start/Run General Purpose Motor, 1 1/2 hp HP, 115/208-230V AC Voltage, 56H Frame MPN:5KCR48WN0273
Capacitor-Start/Run General Purpose Motor, 1 1/2 hp HP, 115/208-230V AC Voltage, 56H Frame
This 1.5 hp single-phase motor from Leeson is designed for general-purpose applications, featuring a capacitor-start/run design for efficient operation. Suitable for use at 115, 208, and 230V AC, it provides reliable performance in a variety of settings. With a 14.5/7.3-7.1 amp rating and 1,725 RPM, it's ideal for applications requiring moderate power and speed. The totally enclosed fan-cooled design ensures efficient heat dissipation, making it suitable for use in environments with limited airflow. Perfect for industrial settings, commercial facilities, and residential applications, this motor offers a reliable and efficient solution for motor-driven equipment.
Top product features:
- Totally Enclosed Fan Cooled design for improved durability and reduced maintenance
- Capacitor-Start/Run motor design for efficient operation and reliable starting
- Continuous duty cycle for uninterrupted performance in demanding applications
Top product applications:
- Industrial conveyor systems
- Pumping systems for small water treatment plants
- Air compressors for small workshops
General Purpose Motor, Single Phase, Motor Design Capacitor-Start/Run, 1 1/2 hp HP, Nameplate RPM 1,725 RPM, No. of Speeds 1, Voltage 115/208-230V AC, Full Load Amps 14.5/7.3-7.1 A, 56H Frame, Usable @ 208V Usable at 208V, Usable @ 200V Not Usable at 200V, Hz 60 Hz, Motor Service Factor 1.15, Max. Ambient Temp. 40 Degrees C, Motor Thermal Protection None, Duty Cycle Continuous, Ins. Class B, Motor Enclosure Design Totally Enclosed Fan Cooled, Motor Shaft Rotation CW/CCW
Additional Information
- Country of Origin: MX
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 15.44
- Package Width: 10.19
- Package Height: 9.50
- Package Weight: 44.00
Product info last updated on March 19, 2026 1:32am UTC
Category: Motors
